Bale Accumulator

Square Bale Accumulator For 15 Bales on Edge

  • Bales arranged on edge, 5 bales wide/3 bales long
  • Handles bales from 32” to 40” in length
  • The bale group size is 75″ wide and 96′-120″ long
  • 15-bale group offers a 33% time-saving advantage in comparison to a 10-bale group, with each grab from the AE15 containing 50% more bales, and with a 33% reduction in the number of packs
  • Bale arrangement allows a 9’ x 20’ wagon to be completely filled

Twisted Chute

The twisted chute turns each bale onto its side, while the baler provides the force needed to push the bales to the top of the chute.

Stainless Steel Deck

The stainless steel deck provides a better surface for the bales to slide in higher dirt and moisture conditions.

Gravity Driven Gates and Final Bale Lever

As gravity moves the bales downward, the last bale in each row swings a gate to open the next row. The last bale in the grab opens the back gate.

Automatic Lift Gate

The last bale in the grab opens the back gate. As the accumulator unloads itself, springs automatically return all the gates back to their starting position, and the rear gate snaps back shut, ready for the next bale.

Guide Belting

Sharp turns are no problem as the guide belt keeps bales properly aligned and moving up the chute.

Bale Configuration

5 Bales Wide and 3 Bales Long

Group Dimensions

72” Wide and 96” to 120” Long

Approximate Weight

2,480 lbs.

Working Height

11 ft. 1 in.

Working Length

21 ft. 5 in.

Working Width

7 ft. 10 in.
